Siemens 5SY7106-6 Sentron Miniature Circuit Breaker 230/400 VAC 6 A

Product Description

The SIEMENS 5SY7106-6 Sentron miniature circuit breaker is designed for reliable short-circuit and overload protection. Rated at 230/400 VAC and 6 A with a 15 kA interrupt rating, it features a thermal-magnetic trip mechanism. It is suitable for use in residential, commercial, and industrial applications. The device is easily installed and removed with a double slider and has a double-chamber terminal block.

• Clear and visible conductor connection facilitates controls.
• Large and easily accessible wiring space simplifies conductor insertion.
• Double terminal chambers accommodate two wires of different cross-sections.

Product Highlights

Provides reliable short-circuit and overload protection with easy installation and versatile wiring options.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SY7106-6
• Country of Origin: Germany

Technical Specifications

• GTIN: 00040892999716
• UNSPSC: 39121601
• Country of Origin: Germany
• Actuator Type: Handle
• Amperage Rating: 6 A
• Connection Type: Screw
• Enclosure Type: IP20/IP40
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 15 kA
• Mounting Type: DIN Rail
• Number of Poles: 1
• Series: 5SY
• Temperature Rating: -25 to 55 deg C
• Trip Range: 1.13 to 1.45 A
• Wire Size: 14 to 4 AWG
• BABA Compliant: No
• Trip Type: Thermal Magnetic
• Voltage Rating: 230/400 V AC
• Product Type: Miniature Circuit Breaker
• Current Rating: 6A
• Tripping Characteristics: Type B
• Rated AC Voltage: 400V ac
• Breaking Capacity: 15kA
• Range: SENTRON
• IP Rating: IP20
• Standards/Approvals: EN 60898
• Release characteristic: B
• Number of poles (total): 1
• Number of secured poles: 1
• Rated current: 6A
• Rated voltage: 400V
• Rated insulation voltage Ui: 440V
• Rated impulse withstand voltage Uimp: 4 kV
• Voltage: AC
• Frequency: 50 Hz
• Limiting class: 3
• Flush mounting: no
• Coupling neutral conductor: no
• Overvoltage category: 3
• Pollution degree: 3
• Additional equipment possible: yes
• Width in division units: 1
• Explosion protection: no
