Siemens 5SY61206 Sentron Supplementary Protector, 480 VAC, 20 A, 5 kA Interrupt, 1 Poles

Product Description

The SIEMENS 5SY61206 Sentron™ supplementary protector is rated at 480 VAC, 20 A, with a 5 kA interrupt capacity. This B frame, thermal magnetic trip protector is designed with screw connections for 14 to 4 AWG wire and is suitable for DIN rail mounting. It is designed for European residential circuit protection and protection of computers and electronic equipment.

• Type B characteristic designed for European residential circuit protection, this characteristic can also be used for protection of computers and electronic equipment
• Identical wire screw connections on line and load side
• 70 mm D installation

Product Highlights

The Siemens Sentron supplementary protector provides reliable overcurrent protection for electrical circuits in residential and commercial settings.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SY61206
• Country of Origin: Germany

Technical Specifications

• Amperage Rating: 20
• Connection Type: Screw
• Enclosure Type: IP20
• Frame: B
• Frequency Rating: 50/60
• Interrupt Rating: 5
• Mounting Type: DIN Rail
• Number of Poles: 1
• Temperature Rating: -25 to 55
• Trip Type: Thermal/Magnetic
• Voltage Rating: 480
• Wire Size: 14 to 4
• Current Ratng: 20A
• Switch-off capacity: 5kA
• Voltage: 400V AC
• MPN: 5SY6120-6
• Model: Miniature circuit-breaker 1-pole
