Siemens 5SJ4316-8HG42 Miniature Circuit Breaker 277V 16A

Product Description

The SIEMENS 5SJ4316-8HG42 is a Sentron miniature circuit breaker operating at 277 VAC and 16 A. It features a thermal/magnetic trip and is suitable for reverse feed applications. Designed for branch circuit protection, it has an IP20 enclosure and mounts on a 35 mm DIN rail. It is suitable for field wiring applications, 14 to 4 AWG, copper (Cu) only.

• Suitable for reverse feed applications
• D-trip is designed for high inrush loads, magnetic trip point is 10 to 20 times the MCB rating
• 35 mm DIN standard mounting rail

Product Highlights

Sentron miniature circuit breaker with thermal/magnetic trip, designed for branch circuit protection and DIN rail mounting.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4316-8HG42
• Country of Origin: United States

Technical Specifications

• Brand: Siemens
• MPN: 5SJ4316-8HG42
• UPC: Does not apply
• Part Number #: 5SJ4316-8HG42
• SKU #: 2204713
• UNSPSC: 39121601
• Voltage: 277 VAC
• Current: 16 A
• Frequency: 50 Hz
• Interrupt Rating: 14 kA
• Trip Type: Thermal/Magnetic
• Poles: 3 Pole
• Phase: 3 ph
• Actuator: Handle Actuator
• Connection: Screw Connection
• Wire Size: 14 to 4 AWG
• Enclosure: IP20 Enclosure
• Mounting: DIN Rail Mounting
• Operating Temperature: -25 to 55 deg C
• Calibration Base: 40 deg C calibration base (industrial applications)
