Siemens 5SJ4303-7HG42 Miniature Circuit Breaker 3A 3P 440V C Curve DIN Rail 5SJ Series

Product Description

The SIEMENS 5SJ4303-7HG42 is a miniature circuit breaker from the 5SJ Series. This 3-pole breaker has a current rating of 3A and a voltage rating of 440V. It is designed for DIN rail mounting and features a C curve characteristic, suitable for general device protection in control circuits.

• DIN Rail Mounting
• C-Trip designed for general device protection
• Suitable for reverse feed applications

Product Highlights

Miniature circuit breaker with 3A current rating, 440V voltage rating, and C curve, designed for DIN rail mounting.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4303-7HG42
• Country of Origin: DE

Technical Specifications

• Manufacturer Part Number: 5SJ4303-7HG42
• Manufacturer: SIEMENS
• Mounting Type: DIN Rail Mount
• Number of Poles: 3
• Series: 5SJ Series
• Voltage Rating: 440 V
• Current Rating: 3 A
• Characteristic: C Curve
• Phase: 3
• Frequency Rating: 50 Hz
• Type: Type NSJ
• Actuator Type: Handle
• Wire Size: 14 to 4 AWG
• Interrupt Rating: 14 kA
• Connection Type: Line/Load/Screw
• Trip Type: Thermal Magnetic
• Temperature Rating: -25 to 55 deg C
• Enclosure Type: IP20
• Brand: INDUSTRIAL MRO
• MPN: 5SJ4303-7HG42
• Voltage Rating - AC: 400 V
• Voltage Rating - DC: 125 V
• Part Status: Active
• Illumination: None
• Approval Agency: CCC, CE, CSA, EAC, UL, VDE
• Current Rating (Amps): 3A
• Application: BRANCH CIRCUIT PROTECTORS
• Connection: Identical wire screw connections on line and load side.
• Country of Origin: DE
• Frequency_Rating: 50
• Interrupt_Rating: 14kA
• Number_Of_Poles: 3
• Special Features: 3-POLE
• Standard: UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2
