Siemens 5SJ4225-7HG42 Sentron Miniature Circuit Breaker 25 A

Product Description

The Siemens 5SJ4225-7HG42 Sentron Miniature Circuit Breaker, Type NSJ, operates at 277/480 VAC and 50 Hz with a 25 A current. It features a 10 kA interrupt capacity and a thermal magnetic trip. Suitable for branch circuit protection and reverse feed applications. Dimensions are 121 mm H x 36 mm W x 70 mm D.

• 40 deg C calibration base (industrial applications)
• Can be used for field wiring applications, 14 to 4 AWG, copper only
• C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems, magnetic trip point is 5 to 10 times the MCB rating

Product Highlights

The Siemens Sentron miniature circuit breaker offers reliable circuit protection with visible ON/OFF indication and easy DIN rail mounting.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4225-7HG42
• Country of Origin: DE

Technical Specifications

• Brand: Siemens
• Part Number #: 5SJ4225-7HG42
• SKU #: 2209114
• Type: Type NSJ
• Connection type: Line/Load/Screw
• UNSPSC: 39121601
• UPC: 00754554959917
• Amperage Rating: 25
• Application: BRANCH CIRCUIT PROTECTORS
• Connection: Identical wire screw connections on line and load side.
• Country of Origin: DE
• Frame: NSJ
• Frequency_Rating: 50
• Interrupt_Rating: 10
• Mounting_Type: DIN Rail
• Number_Of_Poles: 2
• Phase: 1
• Special Features: 0.75 to 35 sq-mm solid and stranded conductors 30 deg C calibration base 35 mm DIN rail mounting 40 deg C calibration base (industrial applications) C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems, magnetic trip point is 5 to 10 times the MCB rating Can be used for field wiring applications, 14 to 4 AWG, copper only Identical wire screw connections on line and load side Smaller size than traditional MCCBs Touch protection to EN50274 Visible indicator for ON and OFF/trip
• Standard: UL 508, CSA C22.2 No. 14-M 95, UL 508 File No. E328403 CSA
• Sub_Brand: SENTRON
• Temperature_Rating: -25 to 55
• Voltage Rating: 277/480
• Current Rating: 25 A
• Voltage Rating (AC): 480 V
• Voltage Rating (DC): 125 V
• Environmental Classification: RoHS
