Siemens 5SJ4202-8HG41 Miniature Circuit Breaker 240V 2A 14K D-Trip

Product Description

The SIEMENS 5SJ4202-8HG41 is a miniature circuit breaker operating at 240V with a 14kA interrupt capacity. This 2-pole breaker features a D trip characteristic and is designed according to UL 489 standards. It is suitable for branch circuit protection and industrial applications with a temperature range of -25 to 55 deg C.

• 40 deg C calibration base (industrial applications)
• 30 deg C calibration base
• Can be used for field wiring applications, 14 to 4 AWG, copper (Cu) only

Product Highlights

Miniature circuit breaker with D-trip, suitable for high inrush loads and reverse feed applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4202-8HG41
• Country of Origin: Germany

Technical Specifications

• Brand: SIEMENS
• Current Rating: 2 A
• Manufacturer Part Number: 5SJ4202-8HG41
• Number of Poles: 2 Pole
• UPC Code: 754554938998
• Voltage: 240V AC, 125V DC
• Rating - kA IR: 14
• Actuator Style: Toggle Lever
• Mounting: DIN Rail, 35mm
• Terminals: Screw
• Amps: 2A
• Country of Origin: Germany - Subject to change
• Type: Supplementary Thermal Magnetic Breaker
• Trip Range: 1.13-1.45 (Thermal), 10-20 (Magnetic)
• Series: SENTRON
• Actuator Type: Lever
• Packaging: Box
• Illumination: None
• Mounting Type: DIN Rail
• Approval Agency: CCC, CE, EAC, UL489, VDE
• Current Rating (Amps): 2A
• Operating Temperature: -25 to 55 deg C
