Siemens 5SJ4130-7HG40 MCB 1P 240V 30A

Product Description

The SIEMENS 5SJ4130-7HG40 is a miniature circuit breaker (MCB) designed for thermal magnetic overcurrent protection in industrial applications. It features a manual circuit opening mechanism and is not ambient compensated. This MCB mounts on a 35mm DIN rail and is UL489 listed for branch circuit or supplementary protection against overcurrent damage.

• Thermal Magnetic Protection
• Screw Terminals
• DIN Rail Mount

Product Highlights

Provides reliable overcurrent protection with easy installation on DIN rails. Suitable for industrial and branch circuit protection.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4130-7HG40
• Country of Origin: Germany

Technical Specifications

• Category: Circuit Protection
• Circuit Breakers: Circuit Breakers
• Voltage Rating - AC: 400 V
• Manufacturer: Siemens
• Voltage Rating - DC: 60 V
• Series: 5SJ4 Series
• Actuator Type: Lever
• Number of Poles: 1 Pole
• Part Status: Active
• Illumination: None
• Mounting Type: DIN Rail Mount
• Approval Agency: CCC, CE, CSA, EAC, UL, VDE
• Current Rating (Amps): 30A
• MPN: 5SJ4130-7HG40
• Model: 5SJ4130-7HG40
• Country of Origin: Germany
• Brand: SIEMENS
• Amps: 30
• Curve Type: C
• AC Voltage Rating: 240V AC
• DC Voltage Rating: 60V DC
• Max. AIR Rating: 14kA at 240V AC
• Phase: 1
• Meets UL Type: UL 489
• Terminal Connection: Screw Clamp
• Trip Type: Thermal Magnetic
• Circuit Breaker Mounting Style: DIN Rail
• Application: Branch Circuit Protection; Industrial; Reverse Feed
• Min. Wire Size: 14 AWG
• Max. Wire Size: 4 AWG
• Length: 3.54 in
• Width: 0.71 in
• Depth: 2.75 in
• Frame Size: 63A/5SJ4
• Circuit Breaker Actuator: Toggle
• Min. Operating Temp.: -13 00b0F
• Max. Operating Temp.: 113 00b0F
• Standards: CE; CSA C22.2 No. 5-02; cULus; EN 60898; EN 60947-2; UL 489; UL File No. E243414
• Voltage Type: AC/DC
• Characteristic: C Curve
• Current Rating: 30 A
• For Use With: Circuit breakers
• Manufacturer Part Number: 5SJ4130-7HG40
• Type: Thermal/Magnetic
• Voltage Rating: 240 V
