Product Description
The Siemens 5SJ4116-7HG40 Type HSJ Miniature Circuit Breaker is designed for branch circuit protection applications. This circuit breaker operates at 240 VAC and has a current rating of thirty amps with a fourteen kiloamp interrupt rating.
- Thermal/Magnetic trip technology
- Compact design for space-saving installation
- Suitable for industrial and field wiring applications
Product Highlights
This circuit breaker is ideal for use in various applications requiring reliable protection against electrical faults.
Product Information
Standard Information
-
Brand: Siemens
-
MPN: 5SJ4116-7HG40
Technical Specifications
-
Trip Type: Thermal/Magnetic
-
Temperature Rating: -25 to 55 degrees Celsius
-
Frequency Rating: 50 Hz
-
Mounting Type: DIN Rail
-
Wire Size: 14 to 4 AWG
-
Amperage Rating: 30 A
-
Dimensions: 90 mm H x 18 mm W x 70 mm D
-
Type: Type HSJ
-
Voltage Rating: 240 VAC
-
Phase: 1
-
Number Of Poles: 1
-
GTIN: 00754554930961
-
Enclosure Type: IP20
-
Connection Type: Line/Load/Screw
-
Interrupt Rating: 14 kA
-
Actuator Type: Handle
-
Minimum Order Qty: 1
-
UNSPSC: 39121601
-
Standard & Approvals: CSA 22.2 No. 5-02, CE Marked, cULus Listed, IEC/EN 60898, IEC/EN 60947-2, HACR Rated, UL 489 File No. E243414
