Siemens 5SJ4110-8HG41 Sentron Type HSJ Miniature Circuit Breaker, 240 VAC, 10 A, 14 kA Interrupt, 1 Poles, Thermal/Magnetic Trip

Product Description

The Siemens 5SJ4110-8HG41 Sentron Type HSJ Miniature Circuit Breaker is designed for 240 VAC systems, 10 A, and a 14 kA interrupt capacity. This 1-pole breaker features a thermal/magnetic trip mechanism. It is suitable for branch circuit protection applications and accepts 14 to 4 AWG copper conductors.

• 40 deg C calibration base for industrial applications
• Suitable for reverse feed applications
• DIN rail mounting for easy installation

Product Highlights

The Siemens Sentron series provides reliable circuit protection with a compact design and easy installation.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4110-8HG41

Technical Specifications

• Phase: 1
• Actuator Type: Handle
• Connection Type: Line/Load/Screw
• Voltage Rating: 240 VAC
• Amperage Rating: 10 A
• Type: Type HSJ
• Enclosure Type: IP20
• Interrupt Rating: 14 kA
• Wire Size: 14 to 4 AWG
• Number Of Poles: 1
• Mounting Type: DIN Rail
• Temperature Rating: -25 to 55 deg C
• Frequency Rating: 50 Hz
• Trip Type: Thermal/Magnetic
• Application: Branch Circuit Protection Applications
• Standard & Approvals: CSA 22.2 No. 5-02|CE Marked|cULus Listed|IEC/EN 60898|IEC/EN 60947-2|HACR Rated|UL 489 File No. E243414
• Brand: SIEMENS
• Manufacturer: Siemens
• Current Rating (Amps): 10A
• Voltage Rating - DC: 60 V
• Series: 5SJ4
