Siemens 5SJ4108-8HG41 Sentron Type HSJ Miniature Circuit Breaker 8 A

Product Description

The SIEMENS 5SJ4108-8HG41 miniature circuit breaker is designed for optimal protection of electrical systems. This 240 VAC, 8 A breaker features a 14 kA interrupt capacity and thermal/magnetic trip technology. Ideal for branch circuit protection, it's compact and easy to install on DIN rails.

• 40 deg C calibration base for industrial applications
• Suitable for reverse feed applications
• Touch protection to EN50274

Product Highlights

Provides reliable circuit protection with a compact design and easy DIN rail installation.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4108-8HG41
• Country of Origin: DE

Technical Specifications

• Phase: 1
• UNSPSC: 39121601
• Trip Type: Thermal/Magnetic
• Wire Size: 14 to 4 AWG
• Application: Branch Circuit Protection Applications
• Mounting Type: DIN Rail
• Enclosure Type: IP20
• Voltage Rating: 240 VAC
• Connection Type: Line/Load/Screw
• Frequency Rating: 50 Hz
• Temperature Rating: -25 to 55 deg C
• Type: Type HSJ
• Actuator Type: Handle
• Amperage Rating: 8 A
• Interrupt Rating: 14 kA
• Number Of Poles: 1
• Standard & Approvals: CSA 22.2 No. 5-02, CE Marked, cULus Listed, IEC/EN 60898, IEC/EN 60947-2, HACR Rated, UL 489 File No. E243414
