Siemens 5SJ4108-8HG40 stnd 1-pole 240VAC

Product Description

The Siemens 5SJ4108-8HG40 miniature circuit breaker provides short-circuit protection. As a component of the SENTRON protective components for electronic installations, it provides effective protection for personnel and plants by reliably shutting down in the event of an overload or short-circuit. It is designed for 240 VAC applications and has an 8 A breaker featuring a 14 kA interrupt capacity.

• Effective personnel, investment and plant protection against overload and short-circuits.
• Easy to install and replaceable accessories.
• Reliable safety during installation due to standard reach-around and touch protection.

Product Highlights

The Siemens miniature circuit breakers are characterized by effective protection, a wide variety of standardized accessories and reliable safety during installation.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4108-8HG40
• Country of Origin: Germany

Technical Specifications

• UNSPSC Code: 39120000
• Alternate Mfr Part Number: 5SJ4108-8HG40
• Brand: Siemens
• Manufacturer Part Number: 5SJ41088HG40
• Category: Circuit Protection
• Circuit Breakers: Circuit Breakers
• Series: SENTRON
• Actuator Type: Lever
• Number of Poles: 1
• Part Status: Active
• Illumination: None
• Mounting Type: DIN Rail
• Approval Agency: CCC, CE, EAC, UL489
• Current Rating (Amps): 8A
• UNSPSC: 39121601
• Application: Branch Circuit Protectors and Reverse Feed Applications
• Amperage: 8 Amp
• Connection Type: Line/Load/Screw
• Frequency: 50 Hz
• Interrupt Rating: 14 kAIC
• Material: Thermoplastic
• Short Circuit Current: 14 kA
• Standard: UL 489 Rated
• Tc Connection: Identical wire screw connections on line and load side.
• Type: HSJ
• Sub Brand: SENTRON
• Class: D
• Phase: 1
• Trip Type: Thermal/Magnetic
• Wire Size: 14 to 4
• Enclosure Type: IP20
• Voltage Rating: 240
• Frequency Rating: 50
• Temperature Rating: -25 to 55
