Product Description
The Siemens 5SJ4106-8HG42 circuit breaker is designed for branch circuit protection. This miniature circuit breaker is single pole and rated for a maximum current of six amps. It operates at a voltage of 240 volts and is compliant with UL 489 standards. The device features thermal magnetic trip for reliable operation in various applications.
- Single pole design for space-saving installation
- Rated current of 6 amps with a 14 kA interrupt rating
- DIN rail mount for easy installation
Product Highlights
This circuit breaker offers reliable protection and is ideal for use in residential or commercial applications, providing peace of mind for electrical systems.
Product Information
Standard Information
-
Brand: Siemens
-
Country of Origin: Germany
Technical Specifications
-
Catalog Number: 5SJ4106-8HG42
-
Type: Type NSJ
-
Voltage Rating: 240 VAC
-
Amperage Rating: 6 A
-
Interrupt Rating: 14 kA
-
Frequency Rating: 50 Hz
-
Width: 1.000 in
-
Height: 3.3 in
-
Length: 5.5 in
-
Weight: 0.386 lb
-
Connection Type: Identical wire screw connections on line and load side
-
Mounting Type: DIN Rail
-
Application: Branch circuit protection
-
Standards: UL 489, IEC/EN 60898, CSA 22.2 NO. 5-02
