Siemens 5SJ4101-8HG42 MCB 5SJ4 1P 1A D-Trip

Product Description

The SIEMENS 5SJ4101-8HG42 is a miniature circuit breaker (MCB) designed for thermal magnetic overcurrent protection. Suitable for general industrial use, it provides branch circuit and feeder protection. This 1-pole breaker features a manual means for opening the circuit and is not ambient compensated. It is designed for DIN rail mounting and offers screw terminals for secure connections.

• Thermal Magnetic Protection
• Screw Terminals
• Handle Actuator

Product Highlights

Miniature circuit breaker with thermal magnetic protection and screw terminals, ideal for industrial and branch circuit protection.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 5SJ4101-8HG42
• Country of Origin: Germany

Technical Specifications

• Category: Circuit Protection
• Circuit Breakers: Circuit Breakers
• Voltage Rating - AC: 400 V
• Manufacturer: Siemens
• Voltage Rating - DC: 60 V
• Series: SENTRON
• Actuator Type: Lever
• Number of Poles: 1
• Part Status: Active
• Illumination: None
• Mounting Type: DIN Rail
• Approval Agency: CCC, CE, EAC, UL489, VDE
• Current Rating (Amps): 1A
• Alternate Mfr Part Number: 5SJ4101-8HG42
• Approvals: UL 489
• Brand: SIEMENS
• Characteristic: D curve
• Current Rating: 1 A
• Manufacturer Part Number: 5SJ4101-8HG42
• Termination: screw
• Type: Thermal/Magnetic
• Applications: BRANCH CIRCUIT PROTECTORS
• Connection Type: Identical Wire Screw Connections On Line And Load Side.
• Frequency: 50 Hz
• Interrupt Rating: 14 kAIC
• Material: Thermoplastic
• Short Circuit Current: 14 kA
• Standard: IEC,EN 60 898,EN 60 947-2,CSA 22.2 NO. 5-02,UL 489,HACR
• TC Connection: Identical wire screw connections on line and load side.
• Class: D
• Voltage: 400 Volt
• Sub Brand: SENTRON
