Siemens 599-10323 Ball Valve, 2 Way, 1-1/2 in. NPT, 40 Cv

Product Description

The SIEMENS 599-10323 is a 2-way ball valve with a 1-1/2 inch NPT connection and a 40 Cv flow coefficient. It features a chrome-plated ball with a brass stem and is designed for controlling hot or chilled water and up to 50% glycol solutions. It has a 200 psi close-off with ANSI Class IV leakage.

• 200 psi Close-Off With ANSI Class IV Leakage
• Blow-Out Proof Stem Withstands High Pressure
• Universal Mounting Plate

Product Highlights

This ball valve is suitable for use in convectors, fan coil units, radiation and reheat coils. It features a universal mounting plate and a blow-out proof stem.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 599-10323

Technical Specifications

• Service: Water, 50% Water-Glycol Solution
• Close-Off Pressure: 200 psi
• Flow Characteristic: Equal Percentage
• Operating Conditions: 35 F To 250 F (2 C To 121 C)
• Trim: Plated Brass
• Assembly: Valve Only
• Connection: NPT
• Valve Size: 1.5 in
• Valve Piping: 2-Way
• Cv: 40 CV
• Trim Material: Brass
• Pattern: 2-way
• Connections: Female NPT
• Body Pattern: 3 Way, 2 Way
• Leakage Class: ANSI Class 1V
• Body Rating: Forged Brass ASTM B283, C37733
• Maximum Closeoff Pressure: 200 PSI
• Materials Of Construction: Forged Brass or Stainless Steel
• Media Compatibility: 50% Water, Glycol Solutions up to 50%
• Media temperature: 1/2" to 1-1/4" - 35° to 250°F (2° to 121°C) 1-1/2" to 2" - 35° to 230°F (2° to 110°C)
• Actuator Compatibility: Siemens GDE, GLB, GMA, GQD,
• Static pressure: 360 psi (2482 kPa)
• Flow Optimizer: Glass filled polymer
• Ball: Nickel-plated brass or Stainless Steel
• Ball seals: Reinforced PTFE seals with EPDM O-rings
• Female end connections: Brass
• Stem: Brass or stainless steel
• Stem seals: EPDM O-rings
• Angle of rotation: 0 to 90 degrees
• Close-off ratings per ANSI/FCI 70-2: Class IV for A-AB, Class III for B-AB
• Maximum operating differential pressure: 1/2" to 1-1/2": 60 psi; 2": 35 psi
• Material: Brass
• Exterior Finish: Brass, Chrome
• Inlet Connection Type: National Pipe Tapered
• Manufacturer: Siemens
• Valve pattern: 2-way
• Valve cv/GPM: 40
• Valve size: 1.5
• Ansi class: ANSI 250/600 WOG
• Category: Ball Valves
• Connection type: Female NPT
• Flow coefficient: 40 Cv
• Fluid type: Chilled or hot water up to 50% glycol
• Product category: Control Valves & Actuators
• Product subcategory: Ball Valves
• Series: Siemens
• Short desc: Ball Valve, 1-1/2 Inch, 2-Way Normally Open, 40 Cv, Equal-Percentage
• Size: 1 1/2 Inch
• Supplier part number: 599-10323
• Valve trim: Chrome-Plated Ball with Brass Stem
• Valve type: Ball Valve
