Siemens 547-107A Room Pressure Monitor 547-107A

Product Description

The Siemens 547-107A Room Pressure Monitor is designed to monitor low differential pressure in indoor environments. This device is essential for applications where maintaining specific pressure levels is critical, such as in hospital isolation rooms and other protected settings.

• Monitors low differential pressure.
• Configurable for both positive and negative pressure.
• Provides alarms for critical pressure changes.

Product Highlights

The monitor ensures accurate performance with sensor technology that maintains an accuracy of +/-5.0 WC and 0.5% full scale, helping professionals adhere to CDC guidelines for pressure management.

Product Information

Standard Information

• Brand: Siemens
• MPN: 547-107A

Technical Specifications

• Communication: P1
• Operating Voltage: 18-32 Vac
• Display: LCD, 128 × 128 RGB backlit Green LED: Normal Red LED: Alarm
• Housing Material: Fire retardant plastic
• Operating Temperature: 32 to 120 °F, 0 to 50 °C
• Operating Humidity: 5 to 95% rh (non-condensing)
• Mounting Type: 4 × 4 plaster ring
• Pressure Connection: Barbed fittings for 1/4 tubing
• Enclosure Rating: NEMA 1, IP20 rated for indoor applications
• Dimensions: 5.4 W × 8 H × 1.8 D inches
