Siemens 52PP2V2A Heavy Duty/Watertight/Oiltight/Non-Illuminated Push-Pull Operator, 600 VAC, 1NO-1NC, 2 Positions

Product Description

The Siemens 52PP2V2A is a heavy duty, watertight, and oiltight push-pull operator. It is designed for reliable operation in demanding environments. With a contact configuration of one normally open (1NO) and one normally closed (1NC) and two positions, this operator suits various industrial applications.

• Pull-to-unlatch mechanism actuator
• Metal front ring
• Temperature rating from -35 to 70 degrees Celsius

Product Highlights

This push-pull operator can be used in settings requiring durability and secure operation.

Product Information

Standard Information

• Brand: Siemens
• Country of Origin: Mexico

Technical Specifications

• Type: Heavy Duty/Watertight/Oiltight/Non-Illuminated
• Color: Red
• Contact Configuration: 1NO-1NC
• Contact Mode: Maintained
• Enclosure Type: NEMA 1/3/3R/4/4X/12/13/IP20/IP66
• Finish: Polished Chrome
• Material: Metal
• Mfg Standards/Approvals: CSA Certified, UL Listed
• Number of Positions: 2
• Operator Type: Mushroom Head Cap/Pull Release
• Voltage Rating: 600 VAC
• Temperature Rating: -35 to 70 degrees Celsius
• Terminal Type: Screw
• Package Dimensions: 2.9 inches height, 4.9 inches length, 3.2 inches width
• Package Weight: 0.55 lb
