Siemens 3VAE250N1S Breaker 3VA 250A Enc

Product Description

The Siemens 3VAE250N1S is a low voltage circuit breaker enclosure designed for enhanced installation efficiency. This enclosure is suitable for 250A and 150-250A circuit breakers, classified under UL for safety. With NEMA Type 1 surface mount ratings and a robust construction, it caters to various circuit breaker configurations.

• Compatible with 3VA5 and 3VA6 Circuit Breakers
• Surface mounting capability
• Constructed for user-friendly installation

Product Highlights

This circuit breaker enclosure significantly reduces installation costs while saving space in low amperage applications.

Product Information

Standard Information

• Brand: Siemens
• Manufacturer Part Number: 3VAE250N1S

Technical Specifications

• Type: Low Voltage Thermal Magnetic/Electronic Trip Circuit Breaker
• Breaker Type: 3-Pole 3VA5/3VA6
• Breaker/Switch Current Rating: 125/250 Amp
• Enclosure: NEMA 1
• Mounting: Surface
• Approval: UL
• Product UPC: 804766470523
• Weight: 20.800 lb
• Dimensions: 32.3 in (Length), 10.6 in (Width), 5.9 in (Height)
