Siemens 3VA5217-5ED61-0AA0 Molded Case Circuit Breaker, 690 VAC/500 VDC, 250 A, 35 kA Interrupt, 2 Poles, Thermal/Magnetic Trip

Product Description

The Siemens 3VA5217-5ED61-0AA0 is a low voltage molded case circuit breaker. It offers thermal and magnetic trip technology. This circuit breaker is designed for robust circuit protection in various applications.

• Rated current of one hundred seventy-five amps
• Two pole configuration with high interrupt ratings
• Dimensions of four point one inches by seven point three inches by four point two inches

Product Highlights

This circuit breaker is suitable for low voltage applications. It is compatible with various electrical systems.

Product Information

Standard Information

• Brand: Siemens
• MPN: 3VA5217-5ED61-0AA0

Technical Specifications

• Amperage Rating: 250 A
• Voltage Rating: 690 VAC/500 VDC
• Number of Poles: 2
• Interrupt Rating: 35 kA
• Trip Type: Thermal/Magnetic
• Height: 7.28 inches
• Width: 4.13 inches
• Depth: 4.21 inches
• Temperature Rating: -25 to 70 degrees Celsius
• Enclosure Type: IP40
• Frequency Rating: 50/60 Hz
• Country of Origin: Czech Republic
