Siemens 3VA41604ED240AA0 Sentron Low Voltage Molded Case Circuit Breaker 60 A

Product Description

The SIEMENS 3VA41604ED240AA0 Sentron molded case circuit breaker is a low voltage breaker operating at 600 Y/347 VAC and 60 A with a frequency of 50/60 Hz. It features a TM210 thermal magnetic trip and a 3VA41 125 A frame. Designed with a 2 pole configuration and aluminum wire/load side connection, it uses (1) 8 to 3/0 AWG wire.

• Features thermal magnetic trip
• IP40 enclosure
• Without auxiliary releases and auxiliary alarm switches

Product Highlights

This Sentron circuit breaker provides reliable circuit protection with a compact design and robust construction.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3VA41604ED240AA0
• Country of Origin: Mexico

Technical Specifications

• GTIN: 00804766943089
• UNSPSC: 39121616
• Country of Origin: Mexico
• Type: Low Voltage
• Trip Type: Thermal Magnetic
• Number of Poles: 2
• Frequency Rating: 50/60 Hz
• Voltage Rating: 600Y/347 V AC
• Enclosure Type: IP40
• Amperage Rating: 60 A
• Temperature Rating: -25 to 70 deg C
• BABA Compliant: No
• Frame: 3VA41 125 A
• Connection Type: Aluminum Wire/Load Side
• Trip Range: 600 A
• Interrupt Rating: 14 kA at 600 Y/347 V, 25 kA at 480 V, 25 kA at 480 Y/277 V, 65 kA at 240 V
• Wire Size: (1) 8 to 3/0 AWG
• Series: 3VA41
