Siemens 3UG4633-1AL30 Voltage Monitoring Relay 17 to 275 VAC 17 to 275 VDC

Product Description

The Siemens 3UG4633-1AL30 is a digital voltage monitoring relay designed for voltage monitoring in both AC and DC applications. This relay operates within a voltage range of seventeen to two hundred seventy-five volts. It features a width of twenty-two point five millimeters, making it compact and efficient for control cabinets.

• Over-voltage and under-voltage monitoring
• Features a screw terminal connection
• Designed for internal power supply with a response time of zero point one to twenty seconds

Product Highlights

This voltage monitoring relay is a reliable solution for protecting circuits against voltage fluctuations and ensuring operational safety.

Product Information

Standard Information

• Catalog Number: 3UG4633-1AL30
• Brand: Siemens
• Country of Origin: Germany
• Manufacturer: Siemens
• Operating Temperature: -25 to 60 degrees Celsius
• Enclosure Rating: IP20

Technical Specifications

• Voltage Ratings: 17 to 275 VAC/VDC
• Contact Configuration: 1 Changeover Contact (1 CO)
• Contact Rating: 4 Amperes
• Depth: 91 mm
• Dimensions: 22.5 mm x 91 mm x 120 mm
• Weight: 0.350 lb
• Connection Type: Screw
• Display: LCD
