Siemens 3UG4615-1CR20 Voltage Monitoring Relay 160 to 690 VAC 0.1 to 20 Second 2CO 3-Pole

Product Description

The SIEMENS 3UG4615-1CR20 is a voltage monitoring relay designed for three-phase supply voltage. It detects line and voltage faults early, initiating responses to prevent significant damage. This relay operates within a 160 to 690 VAC range and features a 0.1 to 20 second response time. It has removable terminals and can be set to above range, below range, or window monitoring.

• Three Phase Voltage Monitoring
• Insulation Monitoring
• 1CO For Vmin and Vmax Contacts

Product Highlights

Voltage monitoring relay with wide voltage range and adjustable delay times for comprehensive protection.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3UG4615-1CR20
• Country of Origin: Germany

Technical Specifications

• Brand: Siemens
• Product Type: Electronic Component
• Connection Type: Screw Connection
• Terminal: Screw Terminal
• Voltage Range: 160-690 Line
• Alternate Catalog Number: 3UG4615-1CR20
• Amperage Rating: 3/0.1 A
• Catalog Number: 3UG4615-1CR20
• Contact Configuration: 2CO
• Country of Origin: DE
• Enclosure Type: IP20
• Frequency Rating: 50/60 Hz
• Manufacturer: Siemens
• Mounting Type: Snap-On
• Response Time: 0.1 to 20 s
• Standards: UL ListedEAC ApprovedCE CertifiedC-TickCCC CertifiedRCM/DNV-GL ApprovedLloyd's RegisteredRoHS Compliant
• Terminal Type: Screw
• Type: 3-Pole
• Voltage Rating: 160 to 690 VAC/250 VDC
