Siemens 3UB81234EW2 Solid State Overload Relay ESP200 Catalog No 48ATE3S00 10 to 40A Frame Size A1 3-Phase

Product Description

The Siemens 3UB81234EW2 Solid State Overload Relay, ESP200 Catalog No. 48ATE3S00, is a reliable solution for protecting motors. This relay supports a current range of 10 to 40 amps and is ideal for 3-phase applications. It offers both manual and automatic reset functions, making it versatile for various operational needs.

• Current range: 10 to 40 amps
• 3-phase motor protection
• Frame size A1, class 5/10/20/30 adjustable

Product Highlights

This overload relay is designed to protect single-phase and polyphase motors. It features a compact design, making it easy to install and maintain.

Product Information

Standard Information

• Brand: Siemens
• Model: 3UB81234EW2
• Manufacturer: Siemens

Technical Specifications

• General Type: Solid State Overload Relay
• Contact Configuration: 1NO 1NC
• Trip Type: Electronic
• Reset Type: Auto/Manual/Remote
• Contact Rating: B600/R300
• Number of Poles: 3
• Applications: Single phase and polyphase motors
• Operating Temperature: -25 to 60 C
• Frame Size: A1
• Dimensions: Width: 3.55 inches, Height: 3.15 inches, Length: 4.22 inches
• Weight: 0.55 lb
• Country of Origin: Czech Republic
• Mounting: Din Rail
• Standards: cUL, CSA
• UPC: 662643897227
• GTIN: 00662643897227
• Applications: Single phase and polyphase motors
