Siemens 3TX7131-4DC03 Heavy Duty Enclosed Power Relay 24 VDC

Product Description

The Siemens 3TX7131-4DC03 Heavy Duty Enclosed Power Relay delivers reliable performance. Designed for durability, this 24 VDC coil relay features a robust 30 A contact, perfect for both DIN rail and panel mounting applications. Ideal for use in household appliances as well as for distribution boards.

• DPDT contact configuration
• DIN-Rail & Surface Mounted
• 30 A Current Rating

Product Highlights

Heavy duty enclosed power relay with 24 VDC coil and 30 A contact rating. Suitable for DIN rail and panel mounting.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3TX7131-4DC03
• Country of Origin: China

Technical Specifications

• UNSPSC: 39122326
• Application: For Use in household appliances as well as for distribution board
• Coil Voltage: 24V DC
• Mounting Type: DIN Rail/Panel
• Contact Rating: 30 A
• Type: Heavy Duty Enclosed
• Brand: SIEMENS
• Manufacturer Part Number: 3TX7131-4DC03
• Series: 3TX71
• Relay Mounting Style: DIN-Rail & Surface
• Current Rating: 30 A
• Contact Form: DPDT
• Contact Rating (DC): 30 A @ 24V
• Motor Rated: Yes_
• Horsepower @ 120V AC: 1/3 hp
• Horsepower @ 240V AC: 3 hp
• Status Indicator: No Indicator
• Push-To-Test Button: No Test Button
• Electrical Operating Durability: 100,000
• Mechanical Operating Durability: 1,000,000
• Dielectric Strength: 1,500 Vrms Between Contacts; 2,000Vrms Between Poles; 4,000Vrms Between Coil and Contact
• Coil Voltage (Nominal@60Hz): 24V DC
• Number of Pins: 8-Pin
• Control Voltage: 24VDC
• Alternate Mfr Part Number: 3TX7131-4DC03
• Alt Part #: 3TX71314DC03
