Siemens 3SU19000BC310DA0 Backing Plate

Product Description

The SIEMENS 3SU19000BC310DA0 is a backing plate designed for use with industrial control station components. Backing plates provide structural support and mounting reinforcement behind pushbutton and selector switch assemblies, helping to secure operator interface devices to enclosure panels or control station housings. This part measures 2.953 inches long by 2.953 inches wide by 0.039 inches thick and weighs 0.002 pounds, making it a lightweight hardware component. Electricians and industrial control technicians typically install this type of hardware as part of a larger control station assembly or panel modification.

This backing plate is suited for use in industrial and commercial electrical control applications where Siemens 3SU series operator interface components are installed. It is typically used during new panel builds or when retrofitting existing control stations that require additional mounting support for pushbutton or selector switch units. The single-pack quantity makes it appropriate for targeted replacements or small-scale installations.

Key Features

• Compact dimensions: 2.953 inches x 2.953 inches x 0.039 inches for precise fitment behind control station devices
• Lightweight construction at 0.002 pounds, adding minimal load to the assembly
• Designed for use with Siemens 3SU series operator interface components
• Single-unit pack suitable for individual replacements or spot installations
• Low-profile 0.039-inch thickness minimizes depth requirements inside enclosures

Compatibility

Designed as an OEM-style replacement or supplemental hardware component for Siemens 3SU series industrial control station assemblies.

Installation Notes

Installation should be performed by a qualified electrician or industrial maintenance technician. De-energize and lock out the control panel or enclosure before beginning any disassembly or hardware installation. Verify that the backing plate is properly seated and aligned before securing the operator interface device to avoid stress on mounting points. Follow applicable NEC requirements and local electrical codes for control panel work.

Technical Specifications

• Length: 2.953 inches
• Width: 2.953 inches
• Height (Thickness): 0.039 inches
• Weight: 0.002 pounds
• Pack Quantity: 1
• UPC: 80476607927

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3SU19000BC310DA0
