Siemens 3SU10011HB200AA0 Illuminated Push Button

Product Description

The SIEMENS 3SU10011HB200AA0 is an illuminated push button designed for use in industrial control panel applications. This operator device provides a tactile momentary switching action combined with built-in illumination, making it suitable for machine control stations, motor control centers, and other industrial enclosures where status indication and operator input are required simultaneously. Electricians and control panel builders install this type of component during panel assembly or field service. At 0.108 pounds, it is a compact unit measuring 3.346 inches in length by 1.772 inches in width by 1.772 inches in height.

This illuminated push button fits into standard 22mm cutout control panel doors and enclosure faces, a common mounting format across industrial automation equipment. It is used in light manufacturing, process control, HVAC equipment panels, and building automation control stations. The built-in illumination allows operators to confirm device state at a glance, reducing diagnostic time during fault conditions or system startup sequences. Installation is typically performed by licensed electricians or qualified control panel technicians per applicable NEC guidelines.

Key Features

• Illuminated operator head provides visual status indication alongside switching function
• Compact and lightweight at 0.108 pounds for easy panel integration
• Dimensions of 3.346 x 1.772 x 1.772 inches suit tight panel layouts
• Single-unit packaging for individual replacement or new panel builds
• Industrial-grade construction appropriate for machine and process control environments

Compatibility

Designed as an OEM-style replacement or new-installation illuminated push button for 22mm industrial control panel operator stations.

Installation Notes

Installation should be performed by a licensed electrician or qualified control technician. De-energize and lock out the control panel before removing or installing any operator device. Verify the supply voltage and illumination voltage ratings match the panel circuit before wiring. Follow all applicable NEC requirements for industrial control wiring and panel construction.

Technical Specifications

• Weight: 0.108 pounds
• Length: 3.346 inches
• Width: 1.772 inches
• Height: 1.772 inches
• Package Quantity: 1 per pack
• UPC: 80476606402

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3SU10011HB200AA0
