Siemens 3SB3601-0AA21 22 mm 400 VAC 10 Amp 1NO 1NC Momentary Metal Bezel Non-Illuminated Push Button

Product Description

The SIEMENS 3SB3601-0AA21 is a 22mm metallic round pushbutton with 1NO-1NC contact configuration. This complete device features a momentary flush, red non-illuminated button. It is suitable for front mounting with screw-type terminals and has an IP67 enclosure rating. The push button is designed for use in a variety of applications.

• 22mm Pushbutton
• Metallic Round
• 1NO-1NC

Product Highlights

The SIEMENS 3SB3601-0AA21 is a complete momentary pushbutton with a metallic bezel, ideal for industrial applications requiring a robust and reliable control interface.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3SB3601-0AA21
• Country of Origin: CZE

Technical Specifications

• Size: 22.0 mm
• Type: 3SB3 Pushbutton / Indicator Lights
• Brand: Siemens
• Standard: CSA,UL,CE
• Enclosure: IP67
• IP Rating: IP67
• Sub Brand: 3SB
• Applications: Complete unit round
• Mounting Type: Front Mounting
• TC Connection: screw-type terminals
• Connection Type: Screw-Type Terminals
• Operating Cycles: 10M
• Contact Rating: 400 Volt AC 10 Amp, 230 Volt DC 1 Amp
• Front Ring Type: Standard Silver Metal
• Number of Switching Position: 2
• Series: 3SB3
• Standard & Approvals: CCC Certified, CE Certified, CSA Certified, EAC Certified, UL Listed
• Contact Configuration: 1NC-1NO
• Contact Mode: Momentary
• Enclosure Type: NEMA 1/3/4/4X/12/IP67
