Product Description
The SIEMENS 3RV20314VA15 is a circuit breaker designed for motor protection, size S2, class 10, with an A-release of 35...45A and N-release of 650A. It features a screw terminal and standard breaking capacity with a transverse auxiliary switch 1NO+1NC. Suitable for 690 VAC applications.
- Minimizes energy losses through optimized bimetal trip units.
- Reduces inherent power loss and control cabinet heating.
- Suitable for operation in IT systems.
Product Highlights
The SIEMENS 3RV20314VA15 motor protection circuit breaker ensures efficient motor protection with reduced energy losses and reliable performance.
Product Information
Standard Information
-
Brand: SIEMENS
-
Manufacturer Part Number: 3RV20314VA15
-
Country of Origin: China
Technical Specifications
-
UNSPSC Code: 39120000
-
Brand: SIEMENS
-
Current Rating: 45 A
-
Manufacturer Part Number: 3RV20314VA15
-
Series: 3RV2 Series
-
UPC Code: 887621920098
-
Trip Range: 35 to 45/650 A
-
Wire Size: 18 to 3 AWG, 18 to 2 AWG
-
Voltage Rating - AC: 690 V
-
Actuator Type: Rotary
-
Number of Poles: 3
-
Mounting Type: DIN Rail
-
Approval Agency: ATEX, CCC, CE, CSA, EAC, IECEx, UL, VDE
-
Breaker Type: Thermal Magnetic
-
Auxiliary Contact Rating: 1NO-1NC
-
Connection Type: Screw
-
Enclosure Type: IP20
-
Frame: S2
-
Frequency Rating: 50 to 60
-
Interrupt Rating: 4
-
Phase: 3
-
Power Rating: 37
-
Temperature Rating: -20 to 60
-
Trip Type: Magnetic
