Siemens 3RV2031-4PA10 Motor Starter 28-36 Amps AC

Product Description

The Siemens 3RV2031-4PA10 motor starter offers reliable protection and control for three-phase motors. This device is compact and has advanced features suitable for various industrial applications.

• 28-36A current rating
• IP20 protection
• Screw terminals

Product Highlights

This motor starter enhances motor safety and lifespan, simplifies installation and wiring, reduces downtime, and increases efficiency in industrial environments.

Product Information

Standard Information

• Brand: Siemens
• MPN: 3RV2031-4PA10

Technical Specifications

• Amperage Rating: 28 to 36 A
• Voltage Rating: 690 VAC
• Connection Type: Screw
• Enclosure Type: IP20
• Number Of Poles: 3
• Mounting Type: DIN Rail
• Trip Type: Magnetic
• Dimensions: 140 mm H x 55 mm W x 149 mm D
• Frequency Rating: 50 to 60 Hz
• Interrupt Rating: 4 kA
• Series: 3RV2
• Power Rating: 30 kW
• Wire Size: 18 to 3 AWG
• Minimum Order Qty: 1
• Standard & Approvals: CSA, CE, IEC, UL
• Manufacturer: Siemens
