Siemens 3RV20214CA15 Motor Protection Circuit Breaker 18.5 kW

Product Description

The Siemens 3RV20214CA15 Motor Protection Circuit Breaker, SIRIUS series, operates at 690 VAC and 22 A with a power rating of 18.5 kW. It features a 50/60 Hz frequency and a 4 kA interrupt capacity. Designed with a thermomagnetic trip and IP20 enclosure, it supports DIN Rail/Snap-On/Threaded mounting. Suitable for motor protection applications.

• Minimizes energy losses through optimized bimetal trip units.
• Reduces inherent power loss and control cabinet heating.
• Suitable for operation in IT systems.

Product Highlights

The Siemens 3RV20214CA15 is a motor protection circuit breaker with thermomagnetic trip, suitable for industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RV20214CA15

Technical Specifications

• Brand: Siemens
• Part Number #: 3RV20214CA15
• SKU #: 2232357
• Trip Range: 16 to 22/286 A
• Frequency: 50/60 Hz
• Interrupt: 4 kA
• Poles: 3 Pole
• Auxiliary: 1NO-1NC
• Wire: 16 to 12 AWG, 14 to 8 AWG
• Enclosure: IP20
• Mounting: DIN Rail/Snap-On/Threaded
• Temperature: -20 to 60 deg C
• Voltage: 690 VAC
• Current: 22 A
• Power: 18.5 kW
• MPN: 3RV20214CA15
• Series: 3RV2 Series
• Current Rating (Amps): 22A
• Voltage Rating - AC: 690 V
• Actuator Type: Rotary
• Packaging: Box
• Number of Poles: 3
• Part Status: Active
• Illumination: None
• Mounting Type: DIN Rail
• Approval Agency: ATEX, CCC, CE, CSA, EAC, IECEx, UL, VDE
• Breaker Type: Thermal Magnetic
