Siemens 3RV1021-1AA10 Msp, Type

Product Description

The SIEMENS 3RV1021-1AA10 is a thermal-magnetic motor starter protector with a voltage rating of 690V AC and a current rating of 1.6 Amp. It features a trip setting of 1.1 to 1.6 Amp for thermal overload release and a short-circuit release of 21 A. This 3-pole protector is designed for NEMA S0 starter size applications.

• Thermal-magnetic type motor starter protector.
• Suitable for motor protection CLASS 10.
• Screw terminal type for easy connection.

Product Highlights

The SIEMENS 3RV1021-1AA10 offers reliable motor protection with its thermal-magnetic design and adjustable trip settings. Ideal for various industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RV1021-1AA10
• Country of Origin: DEU

Technical Specifications

• Voltage Rating: 690 Volt AC
• Maximum AC Voltage Rating: 690
• Current Rating: 1.6 Amp
• Number of Poles: 3
• Trip Setting: 1.1 to 1.6 Amp (Thermal Overload Release)
• Starter Size: NEMA S0
• Terminal Type: Screw
• Wire Type: (2) 1 to 2.5 Square Millimeter, (2) 2.5 to 6 Square Millimeter (Solid/Stranded)
• Approval: UL 508, CSA C22.2, CE, CCC, EAC
• Country Of Origin: DEU
• MPNs: 3RV1021-1AA10, SIE3RV10211AA10, 3RV10211AA10
• EAN: 4011209281103
• HS Code: 85362010
