Siemens 3RT20251AP00 Power Contactor, 3 Poles, 230V AC, 17 A

Product Description

The SIEMENS 3RT20251AP00 power contactor features 3 poles, a coil voltage of 230V AC, and a full load inductive amperage of 17 A. Suitable for worldwide use, this contactor is climate-proof. It has a full load amps-resistive of 40 A and auxiliary contact configuration of 1NO/1NC. It is designed to handle various horsepower ratings across different phases and voltages.

• Climate-proof design ensures reliable operation in diverse environments.
• Suitable and tested for global applications.
• Auxiliary contact configuration: 1NO/1NC.

Product Highlights

The SIEMENS 3RT20251AP00 power contactor is a versatile solution for motor control and power switching applications, designed for durability and global compatibility.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RT20251AP00
• Country of Origin: Germany

Technical Specifications

• Hz: 50
• Item: Power Contactor
• Depth: 97 mm
• Width: 45 mm
• Height: 85 mm
• Standards: CCC, CSA, EAC, RCM, UL
• Coil Volts: 230 V AC
• Watts Loss: 0.6W (Current Dependent); 7.6W (Current Independent)
• Number of Poles: 3
• HP @ 1 Phase - 120V: 1 hp
• HP @ 1 Phase - 240V: 3 hp
• HP @ 3 Phase - 208V: 3 hp
• HP @ 3 Phase - 240V: 5 hp
• HP @ 3 Phase - 480V: 10 hp
• HP @ 3 Phase - 575V: 15 hp
• Max. Operating Watts: 8 kW (at 400V, AC-3), 23 kW (at 400V, AC-1)
• Electrical Connection: Screws
• Full Load Amps-Inductive: 17 A
• Full Load Amps-Resistive: 40 A
• Aux. Contact Configuration: 1NO/1NC
• Frame / Series / Class / Code: S0
• Brand: SIEMENS
• Contact Current Rating: 16 A
• Control Voltage: 230 V
• Manufacturer Part Number: 3RT20251AP00
• Mounting Type: DIN Rail Mount
• Series: 3RT Series
• Type: General Purpose Contactors
