Siemens 3RQ30181AB01 Sirius Coupling Relay, 6 A, 24 VAC/VDC Coil

Product Description

The SIEMENS 3RQ30181AB01 Sirius coupling relay features a 6 A current rating and a 24 VAC/VDC coil. This relay is designed for general-purpose applications. It has a screw terminal and an IP20 enclosure. The relay is suitable for various industrial and automation applications.

• Snap-On mounting type
• Contact Form: 1CO 1 Form C
• Screw terminal type

Product Highlights

The SIEMENS Sirius coupling relay is reliable for switching applications with its 6A, 24 VAC/VDC coil, and easy installation.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RQ30181AB01
• Country of Origin: Tunisia

Technical Specifications

• Mounting Type: Snap-On
• Frequency Rating: 50/60 Hz
• Amperage Rating: 6 A
• Coil Voltage: 24 VAC/VDC
• Temperature Rating: -25 to 60 deg C
• Contact Form: 1CO 1 Form C
• Enclosure Type: IP20
• Terminal Type: Screw
• Coil Type: Non Latching
• Mfr: Siemens
• Features: Lighted Indicator
• Series: SIRIUS 3RQ3
• Termination Style: Screw Terminal
• Operate Time: 12 ms
• Part Status: Active
• Release Time: 14 ms
• Operating Temperature: -25 C ~ 60 C
• Contact Material: Silver Tin Oxide (AgSnO)
• Approval Agency: CCC, CSA, EAC, UL
• Contact Rating (Current): 3 A
• Relay Type: General Purpose
• Switching Voltage: 250VAC - Max
• Base Product Number: 3RQ301
• Load - Max Switching: 750VA
• Type: Coupling Relay
• Mounting: Snap-On
• Terminals: Screw
• Voltage: 300V
• Amps: 6A
• Coil Volts: 24V AC/DC
• Contact Configuration: 1-CO
• Indicators: Green LED
• Poles: 1P
• Manufacturer: Siemens
• Reference: 3RQ30181AB01
• Item Code: 3RQ30181AB01
• Brand: SIEMENS
• Manufacturer Part Number: 3RQ30181AB01
• Primary Type: Power Relays
