Siemens 3RP1531-1AQ30 Off-delay 24 V UC / 100-127 VAC (22.5 mm)

Product Description

Siemens 3RP1531-1AQ30 is an off-delay timing relay (SIMIREL) designed for control and timing applications. It provides an adjustable off-delay from 0.5 to 10 seconds, a single changeover contact (1 CO), and accepts 24 V UC or 100–127 VAC control voltage. The relay mounts on DIN rail with screw and snap-on options, has a 22.5 mm width, an IP20 enclosure rating, and is rated for up to 10 million operating cycles.

• Adjustable off-delay time range: 0.5–10 s; analog conversion
• Single changeover contact (1 CO) with contact rating R300 / B300; control voltage 24 V UC or 100–127 VAC
• DIN rail screw and snap-on mounting; compact 22.5 mm width; enclosure rating IP20

Product Highlights

Off-delay timing relay, 0.5–10 s range, 1 CO, 24 V UC or 100–127 VAC, DIN rail mounting, IP20

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RP1531-1AQ30

Technical Specifications

• Brand: Siemens
• Manufacturer: Siemens
• Manufacturer Part Number: 3RP1531-1AQ30
• Product Name: Off-delay timing relay (SIMIREL)
• Type: 3RP15 Timing Relay
• Function: Off delay (with auxiliary voltage)
• Conversion Type: Analog
• Time Range: 0.5-10 s
• Contacts: 1 changeover contact (1 CO)
• Contact Rating: R300 / B300
• Control Voltage: 24 V UC / 100-127 VAC
• Mounting Type: Screw and snap-on (DIN mounting)
• Width: 22.5 mm
• Enclosure Rating: IP20
• Operating Cycles: 10,000,000
• Operating Temperature: -25 to 60 °C
• Sub Brand: SIRIUS
• Applications: Control, starting, protective and timing circuits for switching operations involving time delays
• UPC: 754554415260
• GTiN: 00754554415260
