Siemens 3RM13071AA04 Motor Starter, Reversing, Safety, 500V, 1.6-7.0A, 24Vdc

Product Description

The SIEMENS 3RM13071AA04 motor starter is a SIRIUS 3RM1 reversing starter designed for safety applications. It operates at 500V with a current range of 1.6 - 7.0A and uses a 24 V DC screw-type connection system. It is suitable for AC motors and features a solid-state overload relay.

• Hybrid technology benefits of semiconductor technology and relay technology
• Screw and snap-on mounting onto 35 mm standard mounting rail vertical, horizontal or standing

Product Highlights

The SIEMENS 3RM13071AA04 motor starter is ideal for motor control and protection in various industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RM13071AA04
• Country of Origin: Germany

Technical Specifications

• Brand: SIEMENS
• Manufacturer Part Number: 3RM13071AA04
• Motor FLA Range: 1.6-7 A
• Series: 3RM Series
• UPC Code: 887621776275
• Frequency Rating: 50/60 Hz
• Motor Power: 3 hp
• Number Of Poles: 3
• Operating Cycles: 30000000 Cycles
• Overload Relay: Solid-State
• Phase: 3
• Standard & Approvals: UL Listed, CCC, CE, CSA Certified, EAC Standard
• Coil Voltage: 24 VDC
• Connection Type: Thread
• Enclosure Type: IP20
• Amperage Rating: 7 A
• Auxiliary Contact Rating: 1CO
• Action: Reversing
• Wattage: 0.55 to 3 kW
• Voltage Rating: 500 VAC
• Timing: 90 to 120 ms On/40 to 55 ms Off
• Operating Temperature: -25 to 60 deg C
• Number of Motors: 1
• Voltage - Load: 500V
• Current - Output: 7A
• Wattage - Load: 3000 W
• Type: Module
• Voltage - Supply: 24VDC
• Motor Type: AC Motor
• Mounting Type: DIN Rail
• Control / Drive Type: Motor Starter, Reversible
