Siemens 3RM13011AA04 Motor Starter 0.1-0.5A

Product Description

The Siemens 3RM13011AA04 is a motor starter. This fail-safe reversing starter is part of the SIRIUS 3RM1 series. It is designed for 48 to 500 V AC, with a 0.5 A amperage rating and a 24 VDC coil. Suitable for conveyor systems, logistics systems, production machines, machine tools and small elevators.

• Space savings due to functional density
• Endurance and reduced heat losses thanks to hybrid technology
• Less wiring and testing due to integrated functions

Product Highlights

The Siemens 3RM13011AA04 motor starter offers space-saving design and efficient performance for various industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RM13011AA04
• Country of Origin: Germany

Technical Specifications

• Catalog Number: 3RM13011AA04
• Manufacturer: Siemens
• Brand: Siemens
• Country of Origin: Germany
• Made in USA: No
• UPC: 887621775650
• GTIN: 00887621775650
• UNSPSC Code: 39120000
• Motor FLA Range: 0.1-0.5 A
• Series: 3RM Series
• Unit of Measure: EA
• Amperage Rating: 0.5 A
• Coil Voltage: 24 V DC
• Enclosure Type: IP20
• Frequency Rating: 50/60 Hz
• Motor Power: 0 to 0.12 kW
• Number of Poles: 3
• Operating Cycles: 30000000 Cycles
• Operating Temperature: -25 to 60 deg C
• Overload Relay: Solid-State
• Phase: 3
• Setting: 0.1 to 0.5 A
• Timing: 65 to 76 ms On, 30 to 43 ms Off
• Type: Fail Safe Reversing
• Connection type: Screw Terminal
• Article Number (Market Facing Number): 3RM13011AA04
• Product family: SIRIUS 3RM1 motor starters
• Product Lifecycle (PLM): PM300:Active Product
• EAN: 4011209914476
• Commodity Code: 85371098
• LKZ_FDB/ CatalogID: CC-IC10
• Product Group: 3762
• Group Code: R711
