Siemens 3RH21221AG60 Contactor Relay 2NO+2NC AC100V 50HZ 100...110V 60HZ

Product Description

The SIEMENS 3RH21221AG60 is a contactor relay with 2NO+2NC contact configuration. It operates at AC100V 50HZ and 100...110V 60HZ. This auxiliary contactor features screw-type terminals for connection and can be mounted via screw or snap-on to a 35 mm standard mounting rail.

• Contact Configuration: 2NO+2NC
• Voltage: AC100V 50HZ, 100...110V 60HZ
• Connection: Screw-type terminals

Product Highlights

The SIEMENS 3RH21221AG60 contactor relay is suitable for various electromechanical applications requiring reliable switching and easy installation.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RH21221AG60

Technical Specifications

• Item Number: 3RH21221AG60
• Brand: Siemens Electrical
• Coil Voltage: AC
• Connection: screw-type terminals
• Contact Configuration: 2NO+2NC
• Contact Rating: A600 / Q600
• Mounting: screw and snap-on mounting onto 35 mm standard mounting rail
• Operating Temperature: -25 °C ... 60 °C
• Type: Auxiliary contactor
• Sub Brand: SIRIUS
• Coil Power Rating: -99999 W / -99999 W
• Power Factor: 0.8
