Siemens 3RB30162TB0 SIRIUS Solid State Overload Relay 4 to 16 Amps 1NO-1NC Contact Form

Product Description

The Siemens 3RB30162TB0 is a SIRIUS solid state overload relay designed for motor protection. This relay supports an amperage range of four to sixteen amps and features a contact form of one normally open and one normally closed (1NO-1NC).

• Overload protection and phase failure protection.
• Manual and automatic reset functions.
• Size S00, Class 20, directly mounted onto contactor.

Product Highlights

This overload relay is suitable for use in various environments and manufactured with environmentally friendly materials.

Product Information

Standard Information

• Brand: Siemens
• Part Number: Q4139

Technical Specifications

• Amperage Range: 4 to 16 A
• Application: For motor protection
• Contact Form: 1NO-1NC
• Contact Rating: 16 A at 690 VAC
• Country of Origin: CZ
• Dimensions: 79 mm H x 45 mm W x 73 mm D
• Enclosure Type: IP20
• Frequency Rating: 50/60 Hz
• Mfg Standards/Approvals: CCC, CE, CSA Certified, EAC Rated, UL Listed
• Mounting Type: Contactor
• Number of Poles: 3
• Temperature Rating: -25 to 60 deg C
• Terminal Type: Threaded
• Type: Solid State
