Siemens 284-03060 Globe Valve Assembly, 2 Way, 1-1/4 in.

Product Description

The Siemens 284-03060 Globe Valve Assembly is a 2-way valve designed for efficient fluid control in HVAC systems. This model features a NPT connection and boasts a maximum flow coefficient of 16 Cv, suitable for various applications. Its stainless steel trim adds durability and resistance to corrosion. This valve is equipped with a pneumatic actuator for reliable operation and has an eight-inch length with a three-quarter inch stroke. It operates within a pressure span of five psi and includes a factory-mounted positioner.

• ANSI Class 250 construction for high performance
• Spring return actuator for reliable operation
• Includes a factory-mounted positioner

Product Highlights

This globe valve is ideal for controlling steam, water, and glycol solutions up to 50%. It is effective in a variety of temperature conditions, operating between twenty degrees Fahrenheit to two hundred fifty degrees Fahrenheit.

Product Information

Standard Information

• Brand: Siemens
• Part Number: 284-03060

Technical Specifications

• Service: Saturated Steam, Water, Glycol Solutions To 50%
• Mounting Type: NEMA 1
• Close-Off Pressure: 93 psi
• Flow Characteristic: Linear
• Operating Conditions: 20 F To 250 F (-7 C To 120 C)
