Siemens 283-06170 3-Way Mixing Globe Valve Assembly Pneumatic (2.5 in) Replacement 599-06170

Product Description

Siemens 283-06170 is a 3-way mixing globe valve assembly with a 2.5 inch flanged body and 63 Cv capacity. The valve uses bronze trim and a pneumatic 8 inch actuator with a factory-mounted Flowrite 599 series positioner. It provides equal percentage (NC port) and linear (NO port) flow characteristics, a 3/4 inch stroke, 1/8 inch NPT air connection, and a spring return fail-safe.

• 3-way mixing globe valve, 2.5 in pipe size, 63 Cv, bronze trim, flanged connections
• Pneumatic 8 in actuator with Flowrite 599 series positioner, 3/4 in stroke and 5 psi span
• Equal percentage (NC) and linear (NO) flow characteristic; spring return fail-safe; max close-off pressure 36 psi

Product Highlights

3-way mixing globe valve, 2.5 in, 63 Cv; pneumatic 8 in actuator with Flowrite positioner; bronze trim, flanged; ANSI Class 125; operating range 20 to 250 F; 36 psi close-off.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 283-06170
• Country of Origin: United States of America

Technical Specifications

• Brand: Siemens
• Manufacturer Part Number: 283-06170
• Product Name: 3-Way Mixing Globe Valve Assembly
• Valve Type: Globe
• Function: 3-Way Mixing
• Valve Size: 2.5 in
• Cv: 63 Cv
• Trim Material: Bronze
• End Connection: Flanged
• Actuator Type: Pneumatic actuator
• Actuator Size: 8 in
• Stroke: 3/4 in
• Positioner: Flowrite 599 series (factory-mounted)
• Positioner Span: 5 psi
• Air Connection: 1/8 in NPT
• Fail-Safe: Spring return (spring normally closed)
• Fail Safe Position: A - AB Closed
• Flow Characteristic: Equal percentage (NC port) and linear (NO port)
• ANSI Class: ANSI Class 125
• Max Close-Off Pressure: 36 psi
• Operating Temperature Range: 20 F to 250 F (-7 C to 120 C)
• Service: Water, glycol solutions to 50%
• Power / Supply: Pneumatic (compressed air)
• Control Signal: Pneumatic
• Flow Pattern: Mixing
• Actuator Model: 599-01050 + 599-00426
• Replacement MPN: 599-06170
