Siemens 283-03182 Globe Valve Assembly, 2 Way, 1/2 in.

Product Description

The Siemens 283-03182 is a two-way globe valve assembly designed for effective pneumatic control. This valve operates with a flow characteristic that follows the equal percentage principle, making it suitable for a variety of applications. It is perfect for systems handling saturated steam, water, and glycol solutions up to fifty percent concentration. With a close-off pressure rating of two hundred fifty psi, it ensures reliable operation under demanding conditions.

• ANSI Class 250 rating for robustness
• Pneumatic valve actuator with included factory mounted positioner
• 1/8 inch NPT air connection for easy integration

Product Highlights

This valve assembly features a brass trim and operates under a span of five psi, making it a reliable choice for professional applications.

Product Information

Standard Information

• Brand: Siemens
• Part Number: 283-03182

Technical Specifications

• Service: Saturated steam, water, glycol solutions to fifty percent
• Mounting Type: NEMA 1
• Close-Off Pressure: 250 psi
• Flow Characteristic: Equal percentage
• Operating Conditions: Twenty degrees Fahrenheit to two hundred fifty degrees Fahrenheit
• Stroke Length: Three-fourths inch
• Valve Size: One-half inch
