Siemens 274-06626 Globe Valve Assembly 2 Way 3 in

Product Description

The Siemens 274-06626 globe valve assembly is a two-way valve designed for fluid control. It has a size of three inches and features stainless steel trim. The valve is direct-coupled and operates efficiently using a power supply of twenty-four volts AC with a fourteen VA power requirement. It is ideal for water and glycol solutions up to fifty percent concentration.

• Flow coefficient of one hundred Cv
• Normally closed valve with modulating control from zero to ten VDC or four to twenty mA
• ANSI 250 compliant

Product Highlights

This assembly provides reliable control in heating and cooling applications. It is suitable for a variety of medium with excellent flow characteristics.

Product Information

Standard Information

• Service: Water, Glycol Solutions Up To 50%
• Power Consumption: 14 VA

Technical Specifications

• Close-Off Pressure: 200 psi
• Flow Characteristic: Equal Percentage
• Operating Conditions: 5 F To 130 F (-25 C To 150 C)
• CV: 100
• Trim: Stainless Steel
• Actuator: SKD62U
• Fail-Safe: Spring Return
• Pipe Size: 3 in
• Connection: Flanged
• Valve Type: 2-Way
• Nema Rating: Nema 1
• Power Supply: Electric
• Control Signal: 0-10VDC, 4-20mA
• Fail Safe Position: Normally Closed
• Connection Type: Flanged x Flanged
• Flow Capacity (Cv): 100
