Siemens 274-05971 Globe Valve Assembly, 2 Way, 3 in.

Product Description

The Siemens 274-05971 is a globe valve assembly designed for HVAC applications. This 2-way valve features a three-inch size and is constructed with stainless steel trim. It operates with a direct coupled actuator, providing modulating control for optimal performance. The valve is rated for a hundred Cv, ensuring it meets the demands of various operational environments.

• Flanged design for easy installation
• Spring return mechanism with a normally closed position
• Compatible with 24 VAC power supply

Product Highlights

This valve is suitable for a range of media including saturated steam, water, and glycol solutions up to fifty percent concentration.

Product Information

Standard Information

• Available Quantity: 1
• Manufacturer: Siemens

Technical Specifications

• Housing: NEMA 1
• Service: Saturated Steam, Water, Glycol Solutions To 50%
• Power Consumption: 17 VA
• Close-Off Pressure: 22 psi
• Flow Characteristic: Equal Percentage
• Operating Conditions: 5 F To 130 F (-15 C To 55 C)
• Electrical Connections: 1/2 in. NPSM Conduit Opening
