Siemens 268-03005 1 Inch 2-Way N/O Stainless Steel Mixing Valve Actuator Female x Female

Product Description

The Siemens 268-03005 stainless steel mixing valve actuator is designed for reliable operation in HVAC systems. This two-way, normally open valve features a 1 inch female x female connection and operates with a pneumatic actuator responding to 3 to 8 psi. It is well-suited for applications involving hot or cold water, water-glycol solutions, and steam.

• ANSI Leakage Class IV ensures minimal leakage.
• Cartridge-type packing and a large diaphragm for precise flow control.
• Capable of handling pressures from 3 to 8 psi with a flow capacity of 10.0 Cv.

Product Highlights

This actuator combo unit comes with a direct-coupled universal bonnet, simplifying installation and removal. The all-metal construction enhances durability, making it suitable for rigorous industrial applications.

Product Information

Standard Information

• Connection Size: 1 inch
• Connection Type: Female x Female

Technical Specifications

• Body Pattern: 2-Way
• Material: Stainless Steel
• Actuator Size: 4 inches
• Pressure Range: 3 to 8 psi
• Flow Capacity: 10.0 Cv
