Siemens 267-05930 Globe Valve Assembly 2 Way 2-1/2 in.

Product Description

The Siemens Globe Valve Assembly with MPN 267-05930 is designed for controlling flows in HVAC systems. This assembly is made with stainless steel trim and can handle various applications. Its flanged connection makes installation straightforward. The valve operates with a direct coupled actuator that provides reliable performance under different conditions.

• ANSI Class 250 rating
• Modulating control with options for 0 to 10 VDC or 4 to 20 mA
• Non-spring return mechanism ensures the valve stays closed when not powered

Product Highlights

This two-way globe valve is built to manage flow for systems using saturated steam, water, or glycol solutions up to fifty percent concentration.

Product Information

Standard Information

• Brand: Siemens
• Part Number: 267-05930

Technical Specifications

• Pipe Size: 2.5 inches
• Trim: Stainless Steel
• CV: 63
• Close-Off Pressure: 34 psi
• Operating Conditions: 5 F to 130 F (-15 C to 55 C)
• Nema Rating: Nema 1
• Power Supply: Electric
• Flow Characteristic: Equal Percentage
