Siemens 14FUF32AF Motor Starter 120 VAC 13 to 52 Amp 25 Hp 3-Phase 3-Pole Size 2 Non-Reversing

Product Description

The Siemens 14FUF32AF is a three-phase, non-reversing motor starter, optimized for 120 VAC and suitable for motors up to 25 horsepower. Ideal for rigorous industrial applications, this motor starter combines functionality with reliability.

• Three-pole, full-voltage non-reversing starter.
• Built-in solid-state overload relay for motor protection.
• Manual and automatic reset functions.

Product Highlights

Efficiently designed for both space and cost savings, the Siemens 14FUF32AF motor starter features dual-voltage, dual-frequency coils and is easily mounted on any surface. It supports a broad range of accessories and is equipped with an overload test feature for added safety.

Technical Specifications

• Width: 8.2 inches
• Height: 5.7 inches
• Length: 10.1 inches
• Weight: 4.0 lbs
• Voltage: 120 Volt
• Amperage: 45 Amp
• Enclosure Type: Open
• NEMA Size: 2
• Operating Temperature: -20 to 40 degrees Celsius
• Country of Origin: Mexico
