Siemens 14DUD12BA Starter, Fvnr Sz1, 5.5-22A

Product Description

The Siemens 14DUD12BA is a non-reversing motor starter, size 1, featuring an H2 solid-state overload relay with an OLR amp range of 5.5-22A. It includes a 110/120 to 220/240VAC 60Hz coil and is a non-combination type with a NEMA 1 enclosure suitable for indoor general-purpose use. The motor starter supports a 240V load with a current output of 27A.

• Features a solid-state overload relay with versatile reset options.
• Designed for reliable operation for various voltage requirements.
• Suitable for 3-wire pilot control (NO auxiliary contact included).

Product Highlights

This heavy-duty full voltage non-reversing motor starter is designed for robust performance and efficient motor control in industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 14DUD12BA
• Country of Origin: USA

Technical Specifications

• Amperage: 27 Amp
• Power Supply: 240 V
• Number of Poles: 2 Pole
• Number of Phases: 2 Phase
• Phase: 1
• Reset Type: Automatic/Manual/Remote
• Application: Indoor and General Purpose
• Coil Voltage: 110/190 to 220 VAC at 50 Hz, 110 to 120/220 to 240 VAC at 60 Hz
• Enclosure Type: NEMA 1
• Overload Relay: Solid-State
• Voltage Rating: 240
• Connection Type: Screw Terminal
• Frequency Rating: 60
• Operating Temperature: 104
• Type: Heavy Duty Full Voltage Non-Reversing
• Motor Power: 1 hp at 115 VAC/2 hp at 200/208/220/230 VAC
• Amperage Rating: 27
• Manufacturer: Siemens
• Motor Type: AC Motor
• Control / Drive Type: Motor Starter
• Number of Motors: 1
• Voltage - Load: 240V
• Current - Output: 27A
• Wattage - Load: 1491 W
• Voltage - Supply: 110 ~ 240VAC
• Construction Standard: NEMA 600V AC
• Size: NEMA Size 1
• UL Cont. Amps: 27A
• Motor FLA: 5.50-22.00A
• Auxiliary Contacts: (1) NO
