Siemens 14CUB12AA Heavy Duty Full Voltage Non-Reversing Non-Combination Motor Starter

Product Description

The Siemens 14CUB12AA is a heavy-duty, full voltage, non-reversing, non-combination motor starter. Rated at 240 VAC and 18 A, it operates at 60 Hz with a wattage of 8.6 W. Suitable for motors up to 1/8 hp at 115 VAC or 1/4 hp at 200/208/220/230 VAC. Features a solid-state overload relay and an open enclosure.

• Features dual voltage and dual frequency coils.
• Equipped with a solid-state overload relay.
• Has an open enclosure and screw terminal connection.

Product Highlights

This Siemens motor starter is designed for robust industrial applications, offering reliable motor control and protection.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 14CUB12AA
• Country of Origin: Mexico

Technical Specifications

• GTIN: 00783087939974
• UNSPSC: 39121521
• Country of Origin: Mexico
• BABA Compliant: No
• Overload Relay: Solid-State
• Reset Type: Automatic/Manual/Remote
• Auxiliary Contact Rating: 10 A at 600 VAC, 5 A at 600 VDC
• Frequency Rating: 60 Hz
• Full Load Current: 0.75 to 3.4 A
• Enclosure Type: Open
• Motor Power: 1/8 hp at 115 VAC, 1/4 hp at 200/208/220/230 VAC
• Connection Type: Screw Terminal
• Phase: 1
• Amperage Rating: 18 A
• Operating Temperature: 104 deg F
• Wattage: 8.6 W
• Type: Heavy Duty Full Voltage Non-Reversing
• Number of Poles: 2
• Voltage Rating: 240 V AC
• Coil Voltage: 110/190 to 220 V AC at 50 Hz, 110 to 120/220 to 240 V AC at 60 Hz
• NEMA Size: 0
