SHURJOINT SJT77058PE Model 7705 Standard Flexible Coupling 8 in Nominal Thread End Style Ductile Iron Painted

Product Description

The SHURJOINT Model SJT77058PE is a flexible coupling designed for various piping applications. This coupling supports moderate pressure services and offers flexibility to handle misalignment, distortion, thermal stress, and vibration. It is also resistant to seismic activity. It allows for the design of curved layouts in piping systems. The coupling consists of two identical segments made of ductile iron, an EPDM rubber gasket, and plated track bolts and nuts. The standard finish for the segments is orange or RAL3000 red, with optional finishes including hot dipped zinc galvanized and custom epoxy coatings.

• Works in moderate pressure piping systems
• Flexibility to accommodate misalignment and vibration
• Includes ductile iron construction for durability

Product Highlights

This standard flexible coupling is suitable for a range of general piping uses. It is made for an eight-inch nominal pipe size and designed with a thread end style.

Product Information

Standard Information

• Manufacturer: SHURJOINT
• Part Number: SJT77058PE

Technical Specifications

• Nominal Size: 8 in
• Thickness: 2.44 in
• Length: 13.27 in
• Material: Ductile Iron
• End Style: Thread
• Temperature Rating: -30 to 230 deg F
• Color: Orange/Red
• Dimensions: 10.24 in H
