SharkBite U4016LF Polybutylene Transition Coupling 3/4 in CTS Lead-Free

Product Description

The SharkBite U4016LF is a polybutylene conversion coupling designed to connect polybutylene pipe to PEX, copper, CPVC, and PE-RT pipes easily. This fitting is lead-free and offers a push-to-connect design for quick installation without the need for special tools, crimping, or soldering.

• Compatible with polybutylene, PEX, copper, CPVC, and PE-RT pipes.
• Designed for underground and behind-the-wall applications.
• Certifications: ANSI/NSF 14, ANSI/NSF/CAN 61.

Product Highlights

This coupling facilitates faster installations in tight spaces, and it can be installed while the lines are wet. The fitting features color-coordinated collars for easy identification—gray for polybutylene and tan for other pipe types.

Product Information

Standard Information

• Brand: SharkBite
• MPN: U4016LF

Technical Specifications

• Connection Size: 3/4 in CTS
• Connection Type: Push-to-Connect
• Material: DZR Brass
• Pressure Rating: 200 psi
• Temperature Rating: 200 deg F
• Length: 2.35 in
• Standards/Certifications: ANSI/NSF 14 and 372 certified, ANSI/NSF/CAN 61 certified
• Applications: Transitioning from polybutylene pipe to PEX, copper, CPVC, PE-RT, or HDPE pipe.
