Sharkbite/cash Acme K334A 90 Degree Drop Ear Elbow 1/2 in

Product Description

The SHARKBITE/CASH ACME K334A is a 90-degree Evopex push-to-connect drop ear elbow designed for fast, tool-free water supply connections. It accepts a 1/2-inch push connection on one end and a 1/2-inch male pipe thread (MPT) on the other, making it a versatile fitting for transitioning between push-fit tubing and threaded pipe. Rated for up to 160 psi and 200 degrees F, this elbow handles the pressure and temperature demands of residential potable water systems. Lead-free construction meets drinking water standards. Plumbers and experienced DIYers install this fitting without solvents, glue, or soldering equipment.

The K334A is intended for water supply applications where PEX-compatible tubing terminates at a wall-mount or structural attachment point. The drop ear design allows the fitting to be fastened to a stud or backing plate, providing a stable, fixed outlet for supply connections such as shower arms, tub spouts, or fixture rough-ins. The push-to-connect mechanism accepts compatible PEX pipe, making it well-suited for new construction and retrofit plumbing projects. Each unit is sold individually and packaged in bags with a package quantity of 6 units per pack.

Key Features

• Push-to-connect design requires no special tools, glue, or soldering
• 1/2-inch push inlet x 1/2-inch MPT outlet configuration
• Rated to 160 psi maximum working pressure
• Maximum temperature rating of 200 degrees F
• Lead-free construction for potable water compliance
• Drop ear mounting tabs allow secure fastening to wall framing

Compatibility

Compatible with PEX-compatible pipe materials for water supply systems. Designed as an OEM-style push-to-connect fitting for residential and light commercial water supply plumbing.

Installation Notes

Installation is performed by licensed plumbers or qualified tradespeople following local plumbing codes and IPC guidelines. Shut off the water supply and relieve system pressure before installing or removing any push-to-connect fitting. Ensure pipe ends are cut cleanly and squarely with no burrs before insertion into the push-connect socket. Secure the drop ear tabs to solid backing using appropriate fasteners to prevent movement under water hammer or pressure surges.
